Product Details:
|
| Applicable Industries: | Garment Shops, Manufacturing Plant, Farms, Retail, Advertising Company | Condition: | New |
|---|---|---|---|
| Product Type: | Hat, Scarf, SWEATER | Type: | Jacquard |
| Production Capacity: | 1.6m/S | Power: | 1.5 W |
| Knitting Style: | Flat | Knitting Method: | Double |
| Computerized: | Yes | Weight: | 650 KG |
| Dimension(L*W*H): | 2500*850*1600mm | Warranty: | 1 Year |
| Key Selling Points: | Low Maintenance Cost | Gauge: | 1.5 GG, 3 GG, 12 GG, 14 GG, 2 GG, 16 GG, 9 GG, 5 GG, 10GG, 18GG, 16GG, 8GG, 3-5-7 Multi-gauge, 2.5gg,3gg, ,5gg ,7gg ,8gg, 9gg, 10gg, 12gg, 14gg |
| Knitting Width: | 52 Inch | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Marketing Type: | New Product 2020 |
| Warranty Of Core Components: | 2 Years | Core Components: | Motor, Gearbox |
| Product Name: | Chinese Sweater Computerized Flat Knitting Machine | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Knitting System: | Single Carriage With Double System | Keywords: | Computerized Flat Knitting Machine |
| Knittind Width: | 52 Inch((36-100 Inch All Available )) | Machine Type: | Fully Jacquard Flat Knitting Machine |
| Function: | Knititing Shoes Upper/sweater/hat | Speed: | Higher Speed |
This system is automatic computerized flat knitting machine
Gauge : | 3G,3.5G,5G,7G,8G,9G,10G,12G,14G,16G,3-5-7G multi-gauge | ||||
Knitting width : | 52 inches (60, 72, 80 inches Customizable) | ||||
knitting function: | Jacquard,Transfer,Miss,Intarsia,Pointelle,Cable,Hide And Other Regular Pattern Knitting Fuctions.(Noted:Tuck can't be knitted with other knitting action in same line) | ||||
Knitting speed: | 1.4m/Second(Max), 32 section adjustable | ||||
Knitting system: | Single carriage with Double System | ||||
Stitch density: | Controlled by 32 section electricity, density adjustment driven by stepping motor, range: 0-650 | ||||
Needle Bed Racking: | AC Servo Motor drive, the maximum racking within 2 inches | ||||
Needle Selection System: | 8 section electronic needle actuator | ||||
Yarn Feeder: | 2 pcs Proactive Yarn Feeders | ||||
Stitch system: | 2*8 yarn carriers are arranged on the left and right sides of the 4 double side guide rails. | ||||
Yarn Carriers: | Advanced encoder reading pin.8-stage selecting needle setup composed of special electromagnet is regarded as efficient full width jacquard needle selector. | ||||
Transmission system: | Belt drive, High precision AC servo motor control. | ||||
Data input: | Input and output patterns via USB, PC and Internet | ||||
Protection system: | Automatic stopping device if yarn broken, yarn knot, batching, striking, completion, overload, designated starting and stopping, program error | ||||
Safety device: | The whole machine cover to reduce noise and dust, the protecting cover is equipped with stopping sensor, emergency stopping and power off device | ||||
Network | Has network interface,enable remote-monitoring via network,and connecting with ERP system. | ||||
Power Supply: | Voltage: AC 220V, Frequency: 50HZ/60HZ, Power:1KW | ||||
Volume and weight | 2450*900*1800mm 700kgs | ||||
