Product Details:
|
| Applicable Industries: | Garment Shops, Manufacturing Plant, Farms, Retail, Advertising Company | Condition: | New |
|---|---|---|---|
| Product Type: | Hat, Scarf, SWEATER | Type: | Jacquard |
| Production Capacity: | 1.6m/S | Power: | 1000 W |
| Knitting Style: | Flat | Knitting Method: | Double |
| Computerized: | Yes | Weight: | 650 KG |
| Dimension(L*W*H): | 3150X750X1750MM | Warranty: | 1 Year |
| Key Selling Points: | Low Maintenance Cost | Gauge: | 1.5 GG, 3 GG, 12 GG, 14 GG, 2 GG, 16 GG, 9 GG, 5 GG, 10GG, 18GG, 16GG, 8GG, 3-5-7 Multi-gauge, 2.5gg,3gg, ,5gg ,7gg ,8gg, 9gg, 10gg, 12gg, 14gg |
| Knitting Width: | 80 Inch | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Marketing Type: | New Product 2024 |
| Warranty Of Core Components: | 1 Year | Core Components: | Motor, Gearbox |
| Product Name: | Chinese Sweater Computerized Flat Knitting Machine | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Knitting System: | Single Carriage With Double System | Keywords: | Computerized Flat Knitting Machine |
| Knittind Width: | 52 Inch((36-100 Inch All Available )) | Machine Type: | Fully Jacquard Flat Knitting Machine |
| Function: | Knititing Shoes Upper/sweater/hat | Speed: | Higher Speed |
Gauge : | 10GG, 12GG, 14GG | ||||
Stitch density: | Controlled by 32 section electricity, density adjustment driven by stepping motor, range: 0-650 | ||||
knitting function: | Jacquard,Transfer,Tuck,Miss,Intarsia,Hide | ||||
Knitting speed: | 1.4m/Second(Max), 32 section adjustable | ||||
Knitting system: | single carriage single system | ||||
Roller system: | Roller System: Main and sub roller devices,32 section automatic control, subsection adjustable | ||||
Yarn Carriers: | 6 yarn carriers are arranged on the left and right sides of the 3 double side guide rails. | ||||
Racking: | Racking: AC Servo Motor drive, the maximum racking within 2 inches | ||||
Transmission system: | Belt drive, High precision AC servo motor control. | ||||
Stitch system: | Controlled by stepping motor, 32 section stitch selectable, adjustable scope supported by subdivision technology: 0-650, the stitch of the knitwear can be accurately controlled. | ||||
Needle selection: | 8 section electronic needle actuator | ||||
Date input: | Data input: Input and output patterns via USB, PC and Internet | ||||
Protection system： | Automatic stopping device if yarn broken, yarn knot, batching, striking, completion, overload, designated starting and stopping, program error | ||||
Safety device: | The whole machine cover to reduce noise and dust, the protecting cover is equipped with stopping sensor, emergency stopping and power off device | ||||
Power: | Voltage: AC 220V, Frequency: 50HZ/60HZ, Power:0.8KW | ||||
Volume and weight | Length×width×height: 2500×850×1600mm Net weight :650kg | ||||
